Astell&Kern A&futura SE300 Digital Audio Player
Tax included. Stock information
Pickup also available at Doug Brady HiFi
Usually ready in 1 hour
Astell&Kern A&futura SE300 Digital Audio Player
Platinum Silver
Doug Brady HiFi
Kingsway Studios
Kingsway North
Warrington WA1 3NU
United Kingdom
Equipped with trailblazing audio technology developed in-house and uncompromising craftsmanship, the fourth model in the A&futura range reproduces an entirely new, natural yet dynamic sound.
Immerse yourself into the true analog sound that the SE300 produces with Class-A AMP and R-2R DAC technologies, for the first time in an Astell&Kern player.
A&futura SE300 is equipped with an ultra-refined R-2R DAC, Class A/AB dual amps born with our proprietary TERATON ALPHA technology, and for the first time a self-developed FPGA optimized technology. With these unrivaled components, it offers the true sound philosophy and technology of Astell&Kern.
Key Features
- Fully Discrete 24 bit R-2R DAC for an entirely new, natural yet dynamic analogue sound
- Equipped with 96 ultra-precision 0.01% & TCR10 resistors, the key to Hi-Fi sound in an ultra-precision resistor design
- New Dual AMP (Class A/AB) mode for crisp, dynamic sounds with high efficiency
- Option for OS (Over Sampling) / NOS (Non-Oversampling) modes, choose between a digital processed signal or pure original untouched sound
- Implemented self-developed and optimized FPGA technology relaying digital signals to the R-2R DAC through Astell&Kern's proprietary algorithm
Flowing, ergonomic design
Crafted from a blend of aluminum and stainless steel, the A&futura SE300 has streamlined surfaces to create a firm yet flexible image to reflect the flow of music.
Reimagined user interface
The SE300 also comes with a redesigned Crimson-theme UI/UX so listeners can deeply connect with their music listening experience.
Fully Discrete 24bit R-2R DAC
To ensure the A&futura SE300 audio player better reproduces analog sounds, we set out to combine the DAC and AMP sections for the first time during the initial design phase.
The SE300 comes supplied with an R-2R DAC, instead of a Delta-Sigma DAC that is most commonly used in other audio players. R-2R DAC, also known as Ladder DAC, as it arranges resistors in a ladder form, offers natural yet dynamic Hi-Fi sounds, but it is extremely technical and difficult to execute as it requires complex refined resistor units and hard to manage current controls.
However, despite these technical challenges, after several years for development and a lot of trial and error we have managed to overcome this and create a new analog sound. In the process, we have meticulously selected each and every one of the 96 ultra-precision resistors and finalized our R-2R DAC technology.
SE300 takes us one step closer to realizing analog sound from a digital source and is the result of a long journey taken by Astell&Kern with uncompromising craftsmanship to find the ultimate sound solution.
Supporting Class A/AB Dual AMP Mode
The SE300 comes with a Dual AMP mode. Class A amplification that creates low distortions and natural sounds and a Class AB amplification that plays dynamic sounds with high efficiency so users can pick and choose from the two amps according to their listening preferences and genre of music that they are playing.
Experience the true sounds that only Astell&Kern can deliver with the SE300 that comes with an R-2R DAC and Class A/AB Dual AMPs born from Astell&Kern’s unique proprietary designs that reduces power consumption whilst enhancing output and removing noise.
Class A AMP is an analog amp that offers the best linear output, amplifying signals without distortion or loss of signal and providing soft, warm, and natural sounds. The refined analog signal created directly by the R-2R DAC, reproduces a sound closest to the original analog audio through the organic and powerful Class A AMP.
Class AB AMP is an analog amp that offers a powerful output with the added benefit of high efficiency.
This presents dynamic and crisp sounds with less harmonic distortion.
2-Step Gain Mode for the Perfect Hi-Fi Experience
For seamless use of sensitive IEMs and hard to drive headphones, a device must provide suitable output, respective of the connected device’s specification.
The SE300 supports a 2-step Gain Level mode to create the prefect match for a wide range of headphones and IEMs, maintaining an optimal sound output.
The two-step gain setting with "Normal" and "High Gain" modes can generate a high current output to create a powerful sound and excellent driver control.
With up to 6 Vrms from the balanced connections, driving high-impedance headphones has never been easier.
Wireless Hi-Fi Sound Through BT Sink
BT Sink function connects the SE300 to an external device via Bluetooth, similar to connecting a smartphone with a BT speaker. Music from an external device, such as a smartphone can now be played back in high-quality on the SE300 using the BT Sink function.
New Experience, New User Interface
The SE300 comes with a redesigned Crimson-themed UI/UX transforming into a "true music player" for users to deeply connect with their music listening experience.
The new UI/UX is designed so that users can quickly browse music categories and re-discover songs within their music library.
We also added an easy album art search function so that users can re-discover the joy of viewing and interacting with music album art whilst listening to their music.
The crimson theme focuses on edge, simplicity, and dark mode keywords. The color theme of black with red highlights lowers visual fatigue and offers intuitive user experiences, and many other improvements were made to the device’s user-friendliness of app service, artist view, album sorting, and the album art search function.
-
General Specifications
-
Model
SE300
-
Body Color
Platinum Silver
-
Body Material
Aluminum and Stainless Steel
-
Display
5.46inch HD 1080 x 1920 touch screen
-
Supported Audio Formats
WAV, FLAC, WMA, MP3, OGG, APE, AAC, ALAC, AIFF, DFF, DSF
-
Sample rate
PCM : 8kHz ~ 384kHz (8/16/24/32bits per Sample)
DSD : DSD64(1bit 2.8MHz), Stereo / DSD128(1bit 5.6MHz), Stereo / DSD256(1bit 11.2MHz), Stereo -
Output Level
[Normal] Unbalanced 2Vrms │ Balanced 4Vrms (Condition No Load)
[High] Unbalanced 3Vrms │ Balanced 6Vrms (Condition No Load) -
CPU
Quad-core
-
DAC
Full Discrete R-2R
-
Decoding
Support up to 32bit / 384kHz playback
-
Input
USB Type-C input (for charging & PC & MAC)
-
Outputs
Unbalanced Out (3.5mm), Optical Out(3.5mm)
Balanced Out (2.5mm, only 4-pole supported | 4.4m, only 5-pole supported) -
Wi-Fi
802.11 a/b/g/n/ac (2.4/5GHz)
-
Bluetooth
V5.0 (A2DP, AVRCP, Qualcomm® aptX™ HD, LDAC)
-
Dimensions
3.01” (76.45mm)[W] x 5.49” (139.45mm)[H] x 0.69” (17.6mm)[D]
-
Weight
About 11.18oz (317g)
-
Feature Enhancements
Firmware upgrade supported (OTA)
-
Operating Temperature
0℃ ~ + 40℃ (32℉~ 104℉)
-
Model
-
Audio Performance
-
Frequency Response
±0.038dB (Condition : 20Hz~20kHz) Unbalanced │Balanced
±0.45dB (Condition : 20Hz~70kHz) Unbalanced │Balanced -
S/N
114dB @ 1kHz, Unbalanced │ 115dB @ 1kHz, Balanced (Normal Gain)
115dB @ 1kHz, Unbalanced │ 115dB @ 1kHz, Balanced (High Gain) -
Crosstalk
-135dB @ 1kHz, Unbalanced │ -144dB @ 1kHz, Balanced
-
THD+N
0.006% @ 1kHz, Unbalanced │ 0.006% @ 1kHz, Balanced
-
IMD SMPTE
0.005% 800Hz 10kHz (4:1) Unbalanced │Balanced
-
Output Impedance
Unbalanced Out 3.5mm (1.3ohm) │ Balanced Out 2.5mm (1.3ohm), 4.4mm(1.3ohm)
-
Frequency Response
-
Clock Source
-
Clock Jitter
25pS (Typ)
-
Reference Clock Jitter
500 Femto Seconds
-
Clock Jitter
-
Storage Capacity
-
Built-in Memory
256GB [NAND]
-
External Memory
microSD x1 (Max. 1TB)
-
Built-in Memory
-
Battery
-
Capacity
5,050mAh 3.8V Li-Polymer
-
Charge Time
about 3.5hours (9V 1.67A Charging)
-
Playback Time
about 12hours (Standard : FLAC, 16bit, 44.1kHz, Vol.50, LCD Off, Normal Gain)
-
Capacity
-
Supported OS
-
Windows 10,11(32/64bit) MAC OS X 10.7
-
