Rotel A10mkII +CD11MkII
Couldn't load pickup availability
Rotel A10mkII +CD11MkII
The Rotel A10MKII Integrated Amplifier offers the perfect combination of power and style for the music lover seeking to elevate their listening experience. Constructed around a linear power supply featuring a massive Rotel-built toroidal power transformer, the A10 MKII delivers an authoritative 50 Watts per channel of Class A/B power into 8 ohms, and even higher power into more challenging loudspeakers.
Power supply innovations and critical circuit layout provide physical and electrical separation to lower the noise floor and increase musical dynamics. The multi-tap transformer delivers isolated power to the low voltage sensitive circuits and the high current amplifier output transistors further isolating the signal paths reducing unwanted distortion. This sound-first design supports fast transients and delivers an expressive, open musical performance.
All analogue sources are welcome, with three line-level RCA inputs, and a Moving Magnet compatible Phono stage provided for vinyl lovers. An 1/8” headphone jack with dedicated headphone amplifier circuit is provided on the front panel for private listening sessions.
An intuitive front panel layout includes rotary Bass, Treble, and Balance controls making the A10MKII a joy to use up close, while the included IR remote control, and a motorized analogue volume controller extend ease of use to the listening seat. User friendly features such as a detachable IEC power cord, two 12V trigger outputs, heavy 5 way speaker binding posts, and auto power off functions ensure compatibility with any installation.
CD11MkII CD Player
Digital to Analogue conversion is handled by a premium Texas Instruments PCM5102A 32-bit/384kHz DAC feeding custom-tuned digital low pass filter circuits. This sound-first design renders music on a large, open sound stage with exceptional details, precision, and finesse.
A linear power supply provides isolated outputs to the CD motor control circuit and critical audio circuits reducing noise and distortion presenting even the smallest of details from your CD collection. Intuitive CD control functions on the front panel and included remote control ensure simple operation. The front panel graphic display shows playback status and disc metadata information including the title and artist.
The digital coaxial output allows the CD11MKII to be utilised as a Disc Transport. A rear panel 12V trigger input and RS232 connector allows seamless integration into even the most complex systems. The CD11MKII is available in both black and silver finishes.
A10MkII Integrated Amplifier Specifications
| Power Output |
50 Watts / ch (8 Ohms) |
| Total Harmonic Distortion |
< 0.03% |
|
Intermodulation Distortion (60 Hz : 7k Hz, 4:1) |
< 0.03% |
|
Frequency Response Phono Input Line Level Inputs |
20 Hz - 20k Hz, -0.5 dB, +0.3 dB 10 Hz - 100k Hz, -0.5 dB, +0.05 dB |
|
Damping Factor (20 - 20,000 Hz, 8 Ohms) |
120 |
|
Input Sensitivity / Impedance Phono Input Line Level Inputs |
1.5 mV / 43k Ohms 120 mV / 45k Ohms |
|
Input Overload Phono Input Line Level Inputs |
50 mV 4 V |
|
Tone Controls - Bass / Treble |
± 6 dB at 100 Hz / 10k Hz |
|
Signal to Noise Ratio Phono Input Line Level Inputs |
85 dB 90 dB |
|
Signal to Noise Ratio Phono Input Line Level Inputs |
85 dB 90 dB |
|
Power Requirements USA Europe |
120 V, 60 Hz 230 V, 50 Hz |
| Power Consumption |
150 Watts |
| Standby Power Consumption |
< 0.5 Watts |
| BTU (4 Ohms, 1/8 power) |
450 BTU/h |
|
Dimensions (WxHxD) |
430 x 73 x 347 mm 17” x 2 7/8” x 13 5/8” |
|
Front Panel Height |
60 mm / 2 3/8”. |
|
Weight (net) |
6.6 kg, 14.5 lbs. |
|
Finish |
Black and Silver |
CD11MkII CD Player Specifications
|
Total Harmonic Distortion + Noise: |
0.009% @ 1k Hz |
|
Intermodulation Distortion: |
0.009% @ 1k Hz |
|
Frequency Response: (± 0.5 dB) |
20 - 20,000 Hz |
|
Channel Balance: |
± 0.5 dB |
|
Phase Linearity: |
± 0.5 degree |
|
Channel Separation: |
> 115 dB @ 10k Hz |
|
Signal to Noise Ratio: (A weighting) |
> 125 dB |
|
Dynamic Range: |
> 99 dB |
|
Digital to Analogue Converters: |
Texas Instruments |
|
Analogue Output Impedance: |
470 Ohms |
|
Digital Output: |
0.5 V, Peak to Peak |
|
Load Impedance: |
75 Ohms |
|
Power Requirements (AC) USA Europe |
120 V, 60 Hz 230 V, 50 Hz |
|
Power Consumption: |
15 Watts |
|
Standby Power Consumption: |
< 0.5 Watts |
|
BTU: |
40 BTU/h |
|
Dimensions: (WxHxD) |
430 x 98 x 314 mm |
|
Front Panel Height: |
80 mm / 3 1/8'' |
|
Weight: (net) |
6.2 kg, 13.7 lbs. |
|
Finish: |
Black and Silver |
