| Audio Inputs: |
2 x Optical TOSLink (up to 24bit/192kHz) |
|
2 x Coaxial RCA (up to 24bit/192kHz, DoP 64Fs) |
|
1 x BNC (up to 192kHz, DoP 64Fs) |
|
1 x HDMI ARC |
|
1 x RCA |
|
1 x 5-pin DIN |
|
2 x USB Type A socket (front and rear) |
|
1 x SD card |
| Audio Outputs: |
1 x Stereo power amplifier |
|
1 x RCA sub/pre output |
|
1 x 3.5mm headphone jack |
| Specifications |
|
| Audio Inputs: (Digital) |
2 x Optical TOSLink (up to 24bit/96kHz) |
|
2 x Coaxial RCA (up to 24bit/192kHz, DoP 64Fs) |
|
1 x BNC (up to 192kHz, DoP 64Fs) |
|
1 x HDMI ARC |
| Audio Inputs: (Analogue) |
1 x RCA |
|
1 x 5-pin DIN |
| Audio Inputs: (USB) |
2 x USB Type A Socket (front and rear) |
| Audio Inputs: (Memory Card) |
1 x SD Card |
| Audio Inputs: (Streaming) |
Chromecast Built-In, Apple AirPlay, TIDAL, Spotify® Connect, Bluetooth (AptX HD), Internet Radio, UPnP™ (hi-res streaming), Roon Ready |
| DAB/FM: |
Optional DAB/FM module available (release date to be confirmed) |
| Audio Outputs: (Analogue) |
1 x Stereo power amplifier |
|
1 x RCA sub/pre output |
|
1 x 3.5mm headphone jack |
| Connectivity: (Network) |
Ethernet (10/100Mbps), WiFi (802.11 b/g/n/ac with internal antennae) |
| Connectivity: (Multiroom) |
Serve up to 4 network-connected players via UPnP™ at full CD quality. |
|
Party Mode Streaming: Sync up to six Uniti all-in-one players or other Naim streamers and control via the Naim app. |
| Connectivity: (Updates) |
Update your system wirelessly via the Naim app. |
| Ripping and Storage: (Storage) |
Store up to 20,000 tracks to a local USB connected storage device and serve to a network-connected player. |
| Ripping and Storage: (CD Ripping) |
Create bit-perfect copies of your CDs, store them on the local storage and play back. |
| Formats: (CD Formats) |
Audio CD (Red Book, CD and CD-R) |
| Formats: (Audio Formats) |
WAV - up to 32bits/384kHz |
|
FLAC and AIFF - up to 24bit/384kHz |
|
ALAC (Apple Lossless) - up to 24bit/384kHz |
|
MP3 - up to 48kHz, 320kbit (16 bit) |
|
AAC - up to 48kHz, 320kbit (16 bit) |
|
OGG and WMA - up to 48kHz (16 bit) |
|
DSD - 64 and 128Fs |
| Notes: |
Gapless playback supported on all formats. All formats to 384kHz maximum over wireless network. |
| Internet Radio Provider: |
vTuner premium 5* |
| Internet Radio Formats: |
Windows Media-formatted content, MP3, ACC, OGG Vorbis streams and MMS |
| Power: (Amplifier Output) |
70W per channel into 8 ohms |
| Power: (Power Consumption) |
Typical use: 130W |
|
Network standby mode: <2W |
|
Deep sleep: <0.5W |
| Power (Mains Supply) |
100V, 115V, 230V; 50 or 60Hz |
| User Control (Handheld) |
Zigbee RF4CE |
| User Control (App Control) |
Naim App for iOS and Android |
| User Control: (Front Panel) |
5" colour LCD display and rotary volume control with proximity sensor and four buttons |
| Physical: (Dimensions) |
95mm x 432mm x 265mm (HxWxD) |
| Physical: (Weight) |
12kg |
| Physical: (Finishes) |
Brushed and anodised aluminium |
| Upgrades: (Amplification) |
External power amplifier or sub-woofer |
| Upgrades: (Mains Cable) |
Power-Line mains cable |
| Certification and Licenses: |
Apple AirPlay, Chromecast Built-In, Bluetooth, AptX HD, Zigbee RF4CE, Rovi, HDMI, NTFS, HFS and Wi-Fi. |
