Audiolab 6000A MkII + Bowers & Wilkins 603 S3 + Cables
Couldn't load pickup availability
Audiolab 6000A MkII + Bowers & Wilkins 603 S3 + Cables
Since the inception of the 6000A in 2016, Audiolab’s brand has undergone rapid evolution. The introduction of award-winning models in both digital music playback and integrated amplifier domains has cemented the company’s position at the forefront of audio technology. The 9000CDT, 9000N, 7000CDT, 7000N Play, 9000A, and 7000A models have exemplified Audiolab’s commitment to pushing performance boundaries across a range of price points. With the launch of the 9000A – Audiolab’s most advanced integrated amplifier – and the 7000A, positioned between the high-end 9000A and more affordable 6000A, the brand's engineers have introduced numerous technical advancements, culminating in the 6000A MKII.
A Step-Up
The Audiolab 6000A MKII maintains the original 6000A's role as an accessible yet impressive "step-up" amplifier, ideal for entry-level audiophiles, but now with significant upgrades in both sound and features. Visually, the MKII remains almost identical to its predecessor, ensuring seamless integration with existing components from the 6000, 7000, and 9000 series. This consistency in design allows for an enhanced listening experience while maintaining compatibility across the Audiolab range.
Power Supply
One of the key upgrades in the 6000A MKII is the enhanced transformer and power supply implementation. The design offers increased voltage from the secondary windings of the transformer, with reduced impedance for better control over the power supply voltage. This leads to the signature Audiolab sound – exceptional consistency, dynamic range, crisp definition, and rhythmic timing. The inclusion of a robust 200VA toroidal transformer, paired with four 15,000uF reservoir capacitors, ensures superior control over the music and impressive dynamic performance.
Advanced DAC and Expanded Connectivity
Audiolab has significantly improved the DAC performance in the MKII, now featuring the ESS Sabre ES9038Q2M chipset, an upgrade from the previous ES9018. This flagship DAC supports 32-bit/768kHz PCM and incorporates HyperStream® II architecture and Time Domain Jitter Eliminator, offering ultra-low noise and a remarkable dynamic range. The MKII also boasts expanded connectivity options, including four S/PDIF inputs and a HDMI ARC input for AV system integration. Bluetooth 5.1 aptX HD support further enhances streaming performance with superior range, speed, and quality.
Multi-Functional Operation
The 6000A MKII continues Audiolab’s minimalist philosophy to ensure maximum signal purity, with a precision analogue volume control and independent low-noise power supplies. The amplifier also includes an advanced phono stage with a high-quality, low-noise, JFET-based circuit. Additionally, the dedicated headphone amplifier provides a dynamic and detailed listening experience across a range of headphones. Audiolab has introduced multiple operational modes, including ‘Integrated,’ ‘Pre,’ and ‘Pre-Power,’ offering flexible functionality for various setups, such as connecting the unit to an AV processor for home cinema systems.
A Benchmark in Integrated Amplifiers
The 6000A MKII builds on the reputation of its predecessor by offering outstanding value and high-quality sound in a more refined, versatile, and future-proof package. Audiolab’s continued dedication to improving performance through incremental advancements has resulted in an integrated amplifier that offers even greater performance, ensuring its place as an essential component for audiophiles and enthusiasts alike.
Bowers & Wilkins 606 S3 Speakers
The Bowers & Wilkins 603 S3 is the largest loudspeaker in the 600 Series and is ideal for larger rooms and home theatres. It combines their new Titanium Dome™ tweeter—which offers both clarity of sound, as well as excellent high frequency dispersion—with Continuum cone technology for a truly audiophile experience.
Layered, beautiful details
The 603 S3's new Titanium Dome tweeter delivers smooth and refined high-frequency reproduction, providing an accurate and immersive insight into your favourite music. 603 S3 boasts a new design that dramatically improves the materials used in its tweeter grille mesh, first developed for our revered Signature models. The Titanium Dome tweeters provide exceptional resolution and realism.
Precision and transparency
The Continuum cone avoids the abrupt vocal transitions that can impair conventional drive units. With 603 S3, experience a more open and neutral performance—voices are delivered with precision and transparency.
Upgraded Performance
Based on the set of speaker terminals we introduced in our 700 Series, the new 603 S3's improved design offers a cleaner signal-path between your amplifier and loudspeakers.
6000A MkII Integrated Amplifier Specifications
| General Description: | Integrated Amplifier |
| Design Philosophy and Core Technology: | 2×50W (8 ohms) / 2×75W (4 ohms) |
| Class AB Design |
|
| E5903802M 32-bit DAC |
|
| Bluetooth 5.1 (aptX, aptX HD) |
|
| Dedicated High-Performance Low-Noise MM Phono Stage |
|
| Dedicated Current-Feedback Headphone Amp |
|
| Integrated / Pre-Power / Pre Modes Only | |
| Inputs: | 3 x Analogue |
| 1 x Phono (MM) | |
| 1 x Power Amplifier | |
| 2 x SPDIF (Coax) | |
| 2 x SPDIF (Optical) | |
| 1 x HDMI ARC | |
| 1 x Bluetooth (aptX / aptX HD) | |
| 1 x 12V Trigger | |
| Outputs: | 1 x PRE Amplifier |
| 1 x Stereo Speaker | |
| 1 x Headphone | |
| 1 x 12V Trigger | |
| Sampling Frequency: | Optical / Coaxial: 44.1kHz - 192kHz |
| Pre-Amplifier Section | |
| Gain: | +54dB (Phono MM) |
| Input Sensitivity: | 720mV (Line, Volume = 0dB); 3.1mV (Phono MM, Volume = 0dB) |
| Input Impedance: | 10k (Line); 47k/100pF (Phono MM) |
| Total Harmonic Distortion: (THD) | <0.004% (1kHz @ 2V, Volume = 0dB) |
| Frequency Response: | 20Hz - 20kHz (+/-0.1dB) |
| Output Voltage: | Output Impedance: 2.3V max. (Volume = 0dB) |
| Output Impedance: | 120 ohms |
| Signal-to-Noise Ratio: | 110dB (Line, A-weighted); >79dB (Phono MM, A-weighted) |
| DAC | |
| D to A Converter: | ES9038Q2M |
| Total Harmonic Distortion: (THD) | <0.001% (1kHz @ 0dBFS) |
| Output Level: (0dBFS, 1kHz) | 2.05Vrms |
| Max. Sampling Frequency: | Optical, Coaxial: 192kHz |
| Signal-to-Noise Ratio (S/N): | 116dB (A-weighted) |
| Power Amplifier Section | |
| Gain: | +29dB |
| Power Rated Output: | 2 x 50W (8 ohms, THD <1%); 2 x 75W (4 ohms, THD <1%) |
| Frequency Response: | 20Hz - 20kHz (+/-0.3dB) |
| Total Harmonic Distortion: (THD) | <0.003% (1kHz @ 50W / 8 ohms) |
| Input Sensitivity: | 720mV |
| Signal-to-Noise Ration (S/N) | >109dB (A-weighted) |
| Max. Output Current: | 11A |
| Headphone Amplifier | |
| Total Harmonic Distortion: (THD) | <0.01% (1kHz, 50mW) |
| Output Impedance: | 2.35 ohms |
| Load Impedance: | 20 - 600 ohms |
| General | |
| Standby Power Consumption: | <0.5W |
| Net Weight: | 7.78kg |
| Gross Weight: | 9.7kg |
| Dimensions (mm) (W x D x H): | 444 x 299 x 65 |
| Carton Size (mm) (W x D x H): | 510 x 465 x 155 |
| Finish: | Black / Silver |
| Power Requirements (depending on region): | 220-240V + 50/60Hz, 100-120V - 50/60Hz |
| Standard Accessories: | Power Cord, Remote Control, User Manual, Antennas, 2 x AAA Batteries |
603 Floorstanding Speaker Specifications
| Size & Weight: | |
| Dimensions: | Height: 985 mm (38.8 in) cabinet only; 1,020 mm (40.2 in) including plinth |
| Width: 190 mm (7.5 in) cabinet only; 260 mm (10.2 in) including plinth | |
| Depth: 340 mm (13.4 in) cabinet only; 368 mm (14.5 in) including grille and terminals; | |
| 402 mm (15.8 in) including plinth | |
| Net Weight: | 27.5kg (60.6 lb) |
| Technical Details: | |
| Technical Features: | Decoupled Double Dome Titanium tweeter; Continuum™ cone FST™ midrange; Paper bass cones; |
| Flowport™ | |
| Description: | 3-way vented-box system |
| Drive Units: | 1x ø25mm (1 in) Titanium Dome high-frequency; 1x ø150mm (6 in) Continuum cone FST midrange; |
| 2x ø165mm (6.5 in) Paper bass cone | |
| Frequency Range: | -6dB 29Hz - 33kHz |
| Frequency Response: | 46Hz - 28kHz ±3dB |
| Sensitivity: | 90dB (on axis at 2.83Vrms at 1m) |
| Harmonic Distortion: | 2nd and 3rd harmonics (90dB, 1m on axis): |
| <1% 100Hz - 22kHz; <0.5% 350Hz - 12kHz | |
| Nominal Impedance: | 8Ω (minimum 3.0Ω) |
| Recommended Amplifier Power: | 30W - 200W into 8Ω on unclipped programme |
| Max Recommended Cable Impedance: | 0.1Ω |
| Finishes: | |
| Cabinet Finishes: | Black; White; Oak |
| Grille Finishes: | Black (Black); Grey (White and Oak) |
