Exposure

Exposure XM7 Preamplifier

£1,750.00
Tax included Shipping calculated at checkout.

Free Next Day Delivery*

Free next weekday delivery

When you spend over £75, we will send you a tracking number where DPD will give a one hour delivery window. Services available Monday to Friday (excluding public holidays) to most mainland UK addresses for in stock items ordered before our cut-off time at 3:30pm. Terms apply.

Free Saturday delivery

When you spend over £299. We will send you a tracking number where DPD will give a one hour delivery window. Services available to most mainland UK addresses for in stock items ordered before our cut-off time on Friday 3pm. Terms apply.

Free Sunday delivery

When you spend over £299. We will send you a tracking number where DPD will give a one hour delivery window. Services available to most mainland UK addresses for in stock items ordered before our cut-off time on Saturday 2pm. (Sunday delivery location) Terms apply.

Reserve for Collection

Some of our manufacturers request for their items not to be sold online. For these items please call to order 01925 828009

Remote locations

Standard next day delivery is free for all orders to most UK mainland addresses. All other delivery prices are determined by the destination, the service chosen and the value and weight of your order. Addresses in the Scottish Highlands, offshore, Northern Ireland & Ireland may incur additional delivery costs, depending on the items ordered.

Returns Policy

If for any reason you’re not completely satisfied with your purchase, we’re happy to offer a refund within 30 days, provided you inform us of your intention within 14 days of receiving your item and return it to us within the 30-day period.

For our full returns policy, click here.

Made in Britain

Exposure has been perfecting the art of creating real Hi-Fi for real music lovers since 1974. Designed, engineered and proudly manufactured in Britain by a talented team of audio engineers who are passionate about the reproduction of music.

Exposure's Hi-Fi components are crafted to exacting standards, offering exceptional value. Their design philosophy prioritizes accurate music reproduction across all genres while maintaining a discreet aesthetic. Known for their user-friendliness and ease of maintenance, Exposure's products deliver precise sound quality. These components provide listeners with an outstanding audio experience, characterized by delicate upper ranges, open mid-range, and deep, agile bass, making them an excellent investment for music enthusiasts.

Half Size, Full Power

Housed in a sleek, half-width design, the Exposure XM7 preamplifier features an integrated moving magnet phonostage for your turntable and DAC with five digital inputs. It also offers a fixed gain home theatre input and dual headphone outputs. Additionally, the XM7 includes two preamp outputs for bi-amping capabilities. This half width preamplifier is the perfect match for the Exposure XM9 Mono power amplifiers.

Features:

  • Large 200W custom-made toroidal power transformer
  • High quality all aluminium casework and extruded front panel
  • High quality resistors & capacitors used in the signal path
  • Cascode circuitry utilised for improved power supply immunity
  • Audio output stages use discrete transistor
  • High quality relays used for input selection
  • 3.5mm & 1/4” headphone outputs selectable by a switch at the back
  • Moving magnet phono input, fixed level AV input and one line level input
  • Two coax ( bnc) and two optical inputs and one class 2 USB input with DSD
  • 2 pairs of pre-amp outputs for bi-amping or sub woofer
  • Remote control
  • Three year guarantee
  • Available in black or titanium

Specifications:

Headphone Output:
Output Impedance:

  0 Ohms
Maximum Level into 33 Ohms:

 @ 1kHz & 0.1% THD :   5V RMS
Total Harmonic Distortion:
 @ 2V output, 1kHz :   <0.03%
Maximum Level into 330 Ohms:
 @ 1kHz & 0.1% THD :   8V RMS
Total Harmonic Distortion:

 @ 2V output, 1kHz :   <0.01%



Analogue Inputs:

Pre-Amplifier Output (Input Sensitivity / Impedance / S/N):
 AV Input Fixed Level:
 450mV @ 1kHz > 12K Ohms S/N > 95dB

AUX/PH Input MM:
 2.5mV @ 1kHz, 47K Ohms S/N > 73dB
     Frequency Response:
 +/-0.5dB 50Hz-20kHz. High pass roll off -1.5dB @ 20Hz
 AUX 2 Input Line:
 350mV @ 1kHz > 14K Ohms S/N output gain
x3.75, +11.5dB
Total Harmonic Distortion:
 <0.005% at 1kHz :   @ 1.3V RMS output
     Frequency Response:
 20Hz - 20kHz +/- 0.5dB
     Signal to Noise Ratio:
 ref 1.3V RMS Output :   1kHz >92dB
     Channel Separation @ 20kHz:
 >60dB



 Digital Inputs:
SPDIF Inputs BNC Coax & Optical:  32 - 192kHz @ 16-24 bits
Total Harmonic Distortion: <0.005% at 1kHz @ 1.3V RMS output
Signal to Noise Ratio: ref 1.3V RSM Output :   1kHz : >98dB
USB Input:  Linear PCM 44K1 - 192kHz @ 16-24 bits DSD
x64 (DoP) Asynchronous transfer from host



 General:
Mains Supply:
  110/120V or 220/240V, 50/60Hz (factory set)
Fuse:

T5AL for 110/120V units

T2.5AL for 220/240V units
Power Consumption:
 25W
Dimensions (HxWxD):
  89mm x 218mm x 363mm
Net Weight:
  5kg
Gross Weight:  6kg
