Artera Stereo
From the transformer to the input terminals, each section of the Artera has been engineered from the ground up to ensure power, musicality and stability. The Artera Stereo produces 140 Watts RMS per channel – ample power for driving first-class loudspeakers, unfaltering even under high dynamic and transient conditions thanks to the patented Current Dumping technology. Special attention has also been paid to the newly developed balanced XLR inputs. The robust connections are yet another string to the Artera Stereo's bow, with an incomparable signal to noise ratio.
Current Dumping is essentially a method of marrying the superior sonic purity of Class A amplification with the greater efficiency of Class AB. An extremely high-quality, low-power Class A amplifier provides the signal quality, while a high-power current dumping section delivers the muscle to keep the speakers under control. These two amp circuits are combined via a precision network to perfectly impose the finesse of the Class A output onto the power of the current dumper. The result is a relatively compact and cool-running power amp capable of delivering a captivating combination of dynamic power, vice-like grip and sumptuous sonic detail....
Specifications
General Description | Power Amplifier |
Rated Output Power | 140W 8 ohm (<1% THD,1kHz) |
Total Harmonic Distortion | <0.003% (100W, 1kHz) <0.03% (100W, 20Hz-20kHz) |
Frequency Response | -0.5dB (20Hz-20kHz, ref. 1kHz) -3dB (20Hz-70kHz, ref. 1kHz) |
Input Sensitivity | 980mV(RCA line in) |
Input Impedance | 10kohm (Balanced) 15kohm (Unbalanced) |
Signal to Noise Ration(S/N) | 115dB (A weighted, ref. 140W) |
Maximum Power Consumption | 750W |
Inputs | 2 x XLR, RCA |
Outputs | Speaker A+B |
Standby Power Consumption | <0.5W |
Dimensions (W x H x D) | 320 x 158 x 338mm |
Weight | 15kg |
