Bowers & Wilkins HTM82 D4 Centre Speaker
Couldn't load pickup availability
Bowers & Wilkins HTM82 D4 Centre Speaker
Reverse Wrap Cabinet
Instead of a conventional loudspeaker box, our cabinets are made from a continuous curved section of wood, with the drive units mounted at the heart of the curvature. This stiffer, more inert structure resists mechanical resonances far better and also ensures better dispersion of sound.
Continuum™ Cone Midrange
Introduced as a huge evolutionary change for us in 2015, the Continuum cone midrange drive has swiftly become a fundamental element in every Bowers & Wilkins loudspeaker. With exceptionally low noise, it ensures outstanding resolution without coloration or masking of detail.
Decoupled Midrange Assembly
HTM82 D4 has a dedicated midrange cone using three key Bowers & Wilkins technologies: the Continuum cone, Biomimetic Suspension and midrange decoupling, the latter ensuring minimal interference from the operation of the loudspeaker’s bass drivers. The result is outstanding clarity.
The Science of Sound
Innovation is at the heart of everything we do. We question, we examine, we understand and then we evolve. We use computer modelling to explore and reimagine every aspect of loudspeaker design. Learn more about all the technologies that combine to make 800 Series Diamond™ so special here.
Specifications
| Technical Features: | Diamond Tweeter |
| Solid Body Tweeter-on-Top | |
| Continuum Cone FST™ | |
| Anti-Resonance Plug | |
| Biomimetic Suspension | |
| Matrix™ | |
| Aerofoil Cone Bass Units | |
| Flowport™ | |
| Drive Units: | 3-way vented-box system |
|
1x ø25mm (1in) diamond dome high-frequency |
|
|
1x ø130mm (5in) Continuum cone FST midrange |
|
|
2x ø165mm (6.5in) Aerofoil cone bass units |
|
| Frequency Range: | 33Hz to 35kHz |
| Frequency Response: | 45Hz to 28kHz (+/-3dB from reference axis) |
| Sensitivity (on axis at 2.83Vrms at 1m): | 89dB |
| Harmonic Distortion: | 2nd and 3rd harmonics (90dB, 1m on axis) <1% 100Hz – 20kHz, <0.4% 100Hz – 20kHz |
| Nominal Impedance: | 8Ω (minimum 3.0Ω) |
| Recommended Amplifier Power: | 50W – 200W into 8Ω on unclipped programme |
| Max. Recommended Cable Impedance: | 0.1Ω |
| Dimensions: | Height: 289mm, Width: 715mm, Depth: 369mm |
| Net Weight: | 25.15kg |
| Finishes: |
Cabinet: Gloss Black, White Grille: Black |
