The app also enables you to manage your music servers and Naim streaming products from a single interface, removing the need for multiple applications. Combined with the system’s high-definition colour display, it delivers a smooth, intuitive and enjoyable user experience every day.
This product integrates seamlessly with leading home automation systems, including Control4, Crestron, Elan, RTI, and Savant. Control your Focal & Naim system through a single, intuitive interface, delivering a harmonious, unified experience throughout your home.
705 S3 Speakers
Bowers & Wilkins has just launched their redesigned, third generation 705 S3 Series of loudspeakers and so far we are LOVING what we're hearing! Enhanced by technologies trickled down from Bowers & Wilkins reference 800 D4 Diamond Series as well as some bespoke engineering innovations, this new range looks set to be very special.
Housed in new cabinet with a curved front which not only adds to the new premium high end look and feel, the curved front also enables the speaker drivers to slightly protrude from the cabinet, this ensures minimal interference from sound reflecting off the cabinet, the result minimises distortion and a more open soundstage. On the back the speaker connections have also been upgraded similar to those used on the 805 D4 Diamond.
705 S3’s Carbon Dome tweeter is housed in a Solid Body Tweeter-on-Top enclosure evolved from the latest generation of 800 Series Diamond. That joins a new and subtly curved baffle endowed with an all-new ‘pod’ housing for its Continuum Cone bass/midrange driver.
Experience the detail
This uncompromising two-way speaker reveals subtle nuances in music others miss. Its high-performance features include a solid body Tweeter-on-Top design borrowed from the 800 Series Diamond.
A house for high frequencies
The 700 Series features the latest generation of iconic Solid Body Tweeter-on-Top housing. Its new, more elongated form incorporates a longer tube-loading system to produce an even more free and open sound with high frequencies. The carefully decoupled housing is milled from a single solid block of aluminium to better resist resonance.
Sharper detail
Carbon Dome tweeters are purpose-built for the 700 Series. Delivering a dramatic improvement on the aluminium double dome tweeter, they raise the breakup threshold to 47kHz, for pinpoint imaging accuracy and detail.
Truly amazing sound
Thanks to its composite construction, the Continuum™ cone avoids the abrupt transitions in behavior that can impair the performance of a conventional drive unit. The result is a more open, neutral performance that delivers voices and instruments with precision and transparency.
Uniti Star Lite Streaming Amplifier Specifications
| Audio formats: |
WAV – up to 32-bit/384 kHz
FLAC and AIFF – up to 24-bit/384 kHz
ALAC (Apple Lossless) – up to 24-bit/384 kHz
MP3 – up to 48 kHz, 320 kbit/s (16-bit)
AAC – up to 48 kHz, 320 kbit/s (16-bit)
OGG and WMA – up to 48 kHz (16-bit)
DSD – 64 and 128 Fs
M4A – up to 48 kHz, 320 kbit/s (16-bit)
Gapless playback is supported on all formats.
|
| Product type: |
All-in-one player |
| Supported sampling rates: |
USB: 44.1 kHz–384 kHz (16 to 24-bit)
S/PDIF: 32 kHz–192 kHz (up to 24-bit)
|
| Inputs/Outputs Specifications: |
|
| Analogue inputs: |
1 x RCA
1 x 5-pin DIN
|
| Analogue outputs: |
1 x stereo power amplifier
1 x RCA pair
1 x 3.5 mm headphone jack
|
| Digital inputs: |
2 x optical TOSLink (up to 24-bit/96 kHz)
1 x coaxial RCA (up to 24-bit/192 kHz, DoP 64 Fs)
1 x coaxial BNC (up to 24-bit/192 kHz, DoP 64 Fs)
|
| Power output: |
70 W per channel into 8 ohms, @ 0.1% THD + N, Class AB |
| USB ports: |
2 x USB Type-A sockets (front and rear – 1.6 A charging) |
| Streaming / Sources: |
|
| Wi-Fi: |
Wi-Fi (802.11 b/g/n/ac) with internal antenna, integrated into the heatsink (patent GB2524815B) |
| Internet radio formats: |
Internet Radio (with enhanced Xperi metadata) from the Naim server. Streaming containers: HLS, DASH, OGG. Codecs: MP3, AAC, Vorbis, FLAC, OPUS. |
| Internet radio provider: |
Naim servers |
| Multiroom: |
Multiroom streaming and its "Party Mode" (sync up to six Naim streamers), with control via the Focal & Naim application |
| Network: |
Ethernet (10/100 Mbps), Wi-Fi (802.11 b/g/n/ac with internal antennas) |
| Storage: |
Store up to 20,000 tracks on a locally connected USB storage device and serve them to a network-connected player.
External portable SSD – maximum 1 TB
USB sticks – maximum 128 GB
|
| Streaming – stereo: |
Apple AirPlay 2, Bluetooth, Chromecast, Internet Radio, Qobuz, Qobuz Connect, QQ Music, Roon Ready, Spotify® Connect, Tidal via Tidal Connect or the Focal & Naim app, and UPnP™ |
| Control: |
|
| App control: |
Focal & Naim app |
| Control system: |
Zigbee RF bi-directional remote control |
| Supported mobile operating systems: |
Android, iOS |
| Updates: |
Update your system via a wireless connection through the Focal & Naim app or via an Ethernet cable through the Focal & Naim app |
| User control product: |
5" colour LCD display, rotary volume control with proximity sensor and four buttons |
| Power Supply: |
|
| Automatic standby time: |
User-selectable (2 hours) – ON/OFF |
| Power consumption (standby mode): |
< 0.5 W |
| Power consumption in network standby mode: |
< 2 W |
| Consumption in normal use: |
130 W |
| Mains cable: |
Electrical power cable |
| Mains power supply: |
115 V or 230 V, 50/60 Hz |
| Design: |
|
| Depth: |
26.5 cm / 10.43 in |
| Height: |
9.5 cm / 3.75 in |
| Width: |
43.2 cm / 16.9 in |
| Weight: |
11 kg |
| Compatibility: |
|
| Compatible cables: |
Super Lumina |
| Included Accessories: |
|
| Accessories: |
Remote control |
| Cables provided: |
Power-Line Lite |
705 S3 Bookshelf Speaker Specifications
|
Technical Features:
|
Decoupled Carbon Dome tweeter
|
|
Solid Body Tweeter-on-Top
|
|
Continuum™ cone bass / midrange
|
|
Flowport™
|
|
Description:
|
2-way vented-box system
|
|
Drive Units:
|
1x ø25mm (1 in) Decoupled Carbon Dome high-frequency
|
|
1x ø165mm (6.5 in) Continuum cone bass / midrange
|
|
Frequency Range:
|
45Hz - 33kHz
|
|
Frequency Response:
|
50Hz - 28kHz ±3dB
|
|
Sensitivity:
|
88dB spl (2.83Vrms, 1m)
|
|
Harmonic Distortion:
|
2nd and 3rd harmonics (90dB, 1m on axis)
|
|
<1% 100Hz - 22kHz
|
|
<0.5% 150Hz - 20kHz
|
|
Nominal Impedance:
|
8Ω (minimum 3.7Ω)
|
|
Recommended Amplifier Power:
|
30W - 120W into 8Ω on unclipped programme
|
|
Max Recommended Cable Impedance:
|
0.1Ω
|
|
Size & Weight:
|
|
|
Dimensions:
|
Height: 345mm (13.6 in) cabinet only, 413mm (16.3 in) including tweeter
|
|
Width: 192mm (7.6 in) cabinet only
|
|
Depth: 297mm (11.7 in) cabinet only, 337mm (13.3 in) including grille and terminals
|
|
Weight:
|
9.58kg (21.1 lb)
|
|
Finishes:
|
|
|
Cabinet Finishes:
|
Gloss Black
|
|
Satin White
|
|
Mocha
|
|
Grille Finishes:
|
Black
|
|
Grey (Satin White only)
|
