Rotel RAS-5000 Streaming Amplifier
Couldn't load pickup availability
Rotel RAS-5000 Streaming Amplifier
The Rotel RAS-5000 streaming amplifier is designed to effortlessly fit into your lifestyle and elevate your entertainment experience. You can stream your favorite music from Spotify Connect, Tidal Connect, Internet Radio, or any service available on your computer, tablet, or mobile device via Airplay 2, Google Cast, Roon, or aptX™ HD Bluetooth.
The HDMI ARC (Audio Return Channel) connection ensures dynamic, high resolution sound for your favorite live sports, TV shows, movies, and games directly from your TV powering 220 watts of Class AB output into 4 ohms.
The RAS-5000 is the perfect fusion of advanced audio technology coupled with modern convenience. In addition to streaming and HDMI ARC you’ll also enjoy a wide array of traditional source inputs including Coaxial, Optical and RCA Analog inputs.
The PC-USB input supports PCM and native MQA and MQA Studio decoding. Digital music files up to 32-bit, 384kHz resolution are rendered with ultimate precision thanks to the premium ESS Digital to Analog converter, while the streamlined RAS-5000 ARC connection to your TV ensures dynamic, high resolution sound from your favorite live sports, TV shows, movies, and games.
Like all Rotel amplifiers, the RAS-5000 is constructed around a massive linear power supply featuring a custom toroidal transformer, which allows the RAS-5000 to deliver a staggering 220 watts of Class AB power into 4 ohms. The overengineered power supply delivers ultra low-noise power to all critical components and robust current to the amplifier output transistors to deliver deep, controlled bass energy with exceptional fidelity.
The sleek RAS-5000 is available in both stylish black and sophisticated silver colors to blend seamlessly to any décor, while its user-friendly interface ensures effortless operation. Enhance and simplify your home entertainment experience without compromise today with the Rotel RAS-5000 and immerse yourself in sound.
Specifcations
| POWER OUTPUT | 220 Watts / ch (4 Ohms) 140 Watts / ch (8 Ohms) |
| TOTAL HARMONIC DISTORTION (THD) | <0.03% |
| FREQUENCY RESPONSE |
Line Level Inputs:
10Hz - 100kHz, ±0.5dB
Digital Inputs:
10 Hz – 70k Hz, (±3 dB, MAX)
|
| S/N RATIO (IHF "A" Weighted) |
Line Level Inputs: 103dB
Digital Inputs: 105dB
|
| DIMENSIONS (W × H × D) |
431 x 144 x 425 mm
17” x 5 7/8” x 16” |
| FRONT PANEL HEIGHT |
132.6 mm / 5 1/4”
|
| POWER REQUIREMENTS |
230V, 50Hz
|
|
POWER CONSUMPTION
|
380W
|
|
STANDBY POWER CONSUMPTION
|
<0.5W
|
|
NET WEIGHT
|
15.7 kg, 34.6 lbs
|
|
BTU RATING (4Ω, 1/8th power)
|
1027 BTU/h
|
|
NTERMODULATION DISTORTION
|
(60 Hz : 7k Hz, 4:1)
<0.03%
|
|
DAMPING FACTOR
|
290
|
|
INPUT SENSITIVITY
|
Line Level Inputs: 0.78V
Digital Inputs: -8dBfs
|
|
INPUT IMPEDANCE
|
Line Level Inputs:46k Ohms
Digital Inputs: 75 Ohms
|
|
INPUT OVERLOAD
|
Line Level Inputs: 4.1V
|
|
TONE CONTROLS
|
±10dB at 100Hz / 10kHz
|
|
HDMI
|
Support eARC function
|
|
COAX/OPTICAL DIGITAL INPUT SIGNALS
|
SPDIF LPCM (Up to 24-bit/192kHz)
|
|
PC-USB
|
USB Audio Class 2.0 (up to 24-bit/384kHz)*
*Driver installation required
MQA and MQA Studio (up to 24-bit/384kHz )
Roon Ready
|
