Project Phono Box Phono Stage

£115.00

Tax included Shipping calculated at checkout.

The Pro-Ject Phono Box is one of the most popular phono stages on the market today. Combining affordability, simplicity and great sound.

Includes Pro-Ject 3 Year Manufacturer Warranty (with Registration)

Finish

Product variants

The Pro-Ject Phono Box is one of the most popular phono stages on the market today. Combining affordability, simplicity and great sound; it's a simple addition that helps turntables sing.

Boasting a sophisticated internal design that employs low-noise ICs and precise RIAA equalisation circuitry, the Phono Box is often found used with far more expensive turntables. Simply connect the In and Output cables, push the switch to select Moving Magnet or Moving Coil operation (depending on your turntable cartridge), plug it in and off you go.

The small size of the Phono Box allows for discrete placement near your turntable or behind an existing system....

Features:

Reliable, affordable phono stage
Steps-up low-level cartridge signal to LINE level
Sturdy metal case work allows electronic circuitry to perform at its best
Special low-noise ICs used
Gold-plated RCA connectors
Outboard power supply included
Amplification and RIAA equalisation for MM and MC cartridges
Small size allows installation close to record player

Specifications

Input Impedance:	MM: 47kΩ / 120pF MC: 100Ω / 120pF
Gain:	MM: 40dB MC: 60dB
Output Voltage (Typically):	MM: 300mV (at 1kHz / 3mV) MC: 300mV (at 1kHz / 0.3mV)
Maximum Output:	9.5V (1kHz)
Noise Floor:	MM: 86dB (94dB - A weighted) MC: 68dB (75dB - A weighted)
THD:	MM: 0.01% MC: 0.05%
RIAA Curve Accuracy:	20Hz - 20kHz / max. 0.5dB
Input:	1x Pair RCA Phono Sockets
Line-Level Output:	1x Pair RCA Phono Sockets
Outboard Power Supply:	18V / 500mA DC
PSU:	18V / 500mA DC
Dimensions:	103 x 36 x 104mm 103 x 36 x 115mm (Incl. Sockets)
Weight:	540g
